उत्पाद विवरण:

Place of Origin: Guangdong
ब्रांड नाम: BANGE
प्रमाणन: ISO9001
Model Number: 85 mm movable partition walls

भुगतान & नौवहन नियमों:

Minimum Order Quantity: 10 square meters
मूल्य: US Dollars 80 - 120 per square meters
Packaging Details: Carton package, MDF batten on four section sides , foam board on both front face.
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 square meters per month
सबसे अच्छी कीमत संपर्क करें

विस्तार जानकारी

Open style: sliding Product name: Movable partition walls
Feature: Sound proofing Size: 100 mm
Color: Accept customized Application: Office,hotel,conference room
Panel width: 500 mm--1230 mm Door material: Melamine board
Surface: Melamine,leather,fabric,plywood Position: Interior
हाई लाइट:

movable walls on wheels

,

movable partitions systems

उत्पाद विवरण

Sound Proof Aluminum Movable Restaurant Partition Wall Sliding Open Style

China Suplier Sound Proof Aluminum Movable Restaurant Partition Wall with High Quality



Specification for BUNGE movable partiiton walls:


1. The bare thickness of the movable partition wall is 85 mm, which is suitable for places with ceiling height less than 7 meters, mainly restaurants, restaurants, hotels, office conference rooms, schools, exhibition halls and other places;



2.85 -type partition itself is light and easy to operate, flexible, each door can be a single hanging wheel hanging and sliding, the door plate can be rotated, or two hanging wheel suspension can be full-slide and can be pushed to any place, the sliding stable and smooth to make room for change diversification;



3. The movable partition walls panel is composed of a 6065-T6 high-hardness aluminum alloy frame with internal sound insulation cotton to meet the basic sound insulation requirements for daily use;



4. There are 20mm-30mm telescopic settings on the top and bottom of the movable partition wall, so that the wall will not shake, and humanized design, to avoid various errors caused by uneven ground;
There are special sealing strips on the edge of the



5.85 type movable partition wall to ensure the sealing and flatness between the walls and effectively prevent the transmission of sound waves;



6. The surface of the movable partition wall can be selected according to customer requirements in the fiber board, multi-layer board, fire board, etc., with a fire prevention function;



7. Universal pulleys with omnidirectional rails allow flexible partitions to move to the best position for stacking.



8. The ground does not need to bury the track, does not damage the carpet surface, maintain the overall effect of the hall;



9. A small door can be added to the partition board to facilitate access.

Sound Proof Aluminum Movable Restaurant Partition Wall Sliding Open Style 0

How to install the movable partition walls

As a movable partition walls manufacturer with 12 years of industry experience, it can have its own set of safety specifications in terms of installation technology. Here are some things to note when installing rails.



1. After the movable partition wall rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the shape of the ceiling, the ground modeling, whether there is a skirting on the wall, etc., and communicate with the on-site carpenters in time, and then determine the track installation. position;



2. After the horizontal line is laid down, determine the layout of the air-conditioning duct and fire control pipe, etc. with the construction party to facilitate the determination of the steel structure installation form. It is a straight pull or diagonal support or U-slot fixed, these are responsible installation teams should Do the pre-construction preparations, or else work hastily, affect the on-site construction layout at the time, but also to redo the work, seriously affecting the progress of the construction, but also bring unnecessary trouble to Party A;



3. After the rails are installed, inspect the track horizontally again, and finally perform rust-proof treatment on the steel structure. Then notify Party A to check and explain clearly the position of the track's movable mouth. When clearly indicating the ceiling of the ceiling, the track cannot be fixed with this section, otherwise loading and unloading. The door panel will likely damage the integrity of the ceiling.



Panel Suspension
Top hunge system without the need for a floor track.
Panel Width
Each panel 600mm-1200mm.
Track
Aluminum OR Steel Track
Roller on panel
Single or Double Roller
Panel Frames
Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
Top&bottm seals
Top and bottom pressure retractable seals ensure effortless moved and locked.
Module
700mm - 1200mm maximum.
Panel stacking
Numerous panel stacking options for complete flexibility.
Panel face
MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes
Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard.



Sound Proof Aluminum Movable Restaurant Partition Wall Sliding Open Style 1

Operation



When moving a wall panel there is a 20-25 mm gap between the top of the panel and the head tracks,there is a similar gap between the bottom of the panel and the door.



Once the panel is positioned,acoustic integrity is maintained along the top and the bottom of the panel by extending presure seals.The presure seals are extended and retracted by a single 180 degree turn of a removable of erating handle.



Final closure of the wall is achwared by extending a telescopic sleeve on the last panel.This action simultaneously extends the top and the bottom seals.



These profiles are fitted with magnetic membrances which ensure positive interlocking of the panels.Once the wall panels have been adjusted for height and level the rollers systems are locked with a fail-safe mechanism to ensure that the panels will align perfectly everytime the wall is set up.

Sound Proof Aluminum Movable Restaurant Partition Wall Sliding Open Style 2
